8″ Rugged Tablet PC | MJ-80

Certifications

mj_80

Highlights

The MJ-80 Rugged Tablet is designed to meet the demanding needs of industrial professionals, blending durability with advanced technology. Its 8-inch IPS display (1200×800 resolution) delivers clear, detailed visuals, perfect for viewing industrial data. Powered by an octa-core ARM Cortex-A53 processor and running Android 7.1 (upgradable) or Linux OS, the MJ-80 provides reliable performance for critical industrial applications. With IP65-rated water and dust protection, 4-foot drop resistance (MIL-STD-810G), and up to 8 hours of battery life, it is built to withstand the harshest environments, including frequent sanitization. Optional modules, such as NFC, a barcode reader, and a fingerprint reader, streamline industrial operations and ensure compliance with data security standards. Wi-Fi 5, Bluetooth 4.0, and optional GPS further enhance connectivity, making the MJ-80 an indispensable tool in modern industrial environments.

Features

8″ IPS LCD Display (1200 x 800 Resolution)
Octa-core ARM Cortex -A53 Processor
Android 7.1 (Up Gradable to the Latest Version) or Linux OS
4ft Drop/ Shock Protection (MIL- STD-810G)
IP65 Water & Dust Protection
Long Life Battery – Up to 8 Hours Runtime
Wi-Fi 5, Bluetooth 4.0, Optional GPS
IEC 62133, IEC60601-1
Optional Modules: NFC, Barcode Reader, and Fingerprint Reader

Pricing Based on MOQ

in stock

DESCRIPTION

Enhanced Performance with Octa-core ARM Cortex-A53 Processor

The MJ-80 rugged tablet is designed to deliver reliable performance in demanding medical and industrial environments. Powered by an Octa-core ARM Cortex-A53 processor, the MJ-80 ensures seamless multitasking, allowing healthcare professionals and field workers to manage complex tasks efficiently. With 2GB LPDDR3 memory (upgradable to 4GB) and 32GB of eMMC storage (expandable to 64GB), the MJ-80 provides ample processing power for handling essential medical applications and patient data in fast-paced settings.

Optimized for Medical and Industrial Use: Android 7.1 or Linux OS

Running on Android 7.1 (upgradable) or optional Linux OS, the MJ-80 is optimized for secure and flexible operations, making it the ideal choice for medical facilities and industrial applications. These operating systems enable smooth integration with medical software, real-time data access, and customizable program management, offering an exceptional user experience in any industry.

Rugged Durability for Harsh Medical Environments

The MJ-80 is built to endure the harshest environments, with an IP65 rating for protection against water and dust, ensuring durability in healthcare facilities where frequent cleaning and sanitization are required. Its rugged design meets MIL-STD-810G standards, providing resistance to drops from 4 ft, shocks, and vibrations, making it a reliable solution for hospitals, clinics, or fieldwork in rugged conditions.

Advanced Touchscreen with Wet and Glove Modes

The MJ-80 features a 10-point capacitive touchscreen engineered for the medical environment, supporting both wet and glove modes to ensure seamless usability in critical situations. Whether medical professionals are wearing gloves or using the device in humid conditions, the MJ-80’s responsive touch technology guarantees reliable performance without interruption. Additionally, the screen is equipped with advanced glass coating options, including anti-reflective, anti-glare, and anti-fingerprint properties. These coatings enhance visibility and ensure a clean display, allowing for optimal performance in any situation.

Fast Connectivity with Wi-Fi 5 and Optional GPS

Stay connected with Wi-Fi 5 and Bluetooth 4.0, enabling fast and stable wireless communication. The MJ-80 also offers an optional GPS module, ensuring precise tracking and data transfer in remote locations, making it the ideal device for fieldwork and healthcare applications that require reliable real-time updates.

Optional Modules for Medical Needs

The MJ-80 offers unparalleled flexibility with optional modules tailored for the medical industry, including a barcode reader, fingerprint reader, and NFC capabilities. These customizable expansion options enhance the tablet’s functionality, making it well-suited for various healthcare applications such as patient identification, medication management, and inventory tracking. This adaptability ensures that the MJ-80 can meet the specific needs of your medical operations, providing healthcare professionals with the tools necessary to deliver efficient and accurate care.

Long-Lasting Battery for Continuous Operations

Equipped with a 24Wh Li-ion Polymer battery, the MJ-80 delivers up to 8 hours of continuous use, ensuring minimal downtime in critical operations. Whether you’re managing patient data in a hospital or working on-site, the MJ-80’s long battery life supports uninterrupted productivity throughout the day.

Certified for Medical-Grade Performance and Safety

The MJ-80 meets stringent medical and industrial certifications, including IEC 62133 and IEC 60601-1, ensuring compliance with safety and operational standards. Built for reliable performance, this rugged tablet is the perfect solution for medical professionals and industries that demand high-quality, certified equipment.

SPECIFICATIONS

RUGGEDNESS

Waterproof

IP65 IEC60529

Drop Rating

MIL-STD-810G, 4ft to Plywood on 26 Corners

Shock Rating

MIL-STD-810G, Method 516.6, Procedure I, 40g 11ms

Vibration Rating

MIL-STD-810G, 514.6, Procedure I Category 4, Category 20, Category 24

ESD Protection

6KV Touch, 8KV Air

EMC Test

Follows FCC

SYSTEM

Processor

RockChip RK3368, 1.5GHz, Octa-core Cortex-A53

GPU

G6110 GPU 4K@60fps H.265 HDMI 2.0 with HDCP 2.2

Memory

2GB LPDDR3-1866

4GB LPDDR3-1866

Android 7.1

Options:

Linux (Custom Projects)

Storage

32GB eMMC 5.1

Options:

64GB eMMC 5.1

DISPLAY

Screen Size

8″ IPS

Resolution

1200 x 800

Brightness

300 NIT

View Angle

+/- 85°

Contrast Ratio

800:1

Touchscreen

Capacitive 10-Point Multi-Touch

Chemically Hardened Cover Glass

Glass Coating Options:

Anti-Reflective

Anti-Glare

Anti-Fingerprint

COMMUNICATIONS

Wi-Fi

AP6255, 802.11 a/b/g/n/ac Dual-Band 2.4G & 5G

Bluetooth

Bluetooth v4.0

GPS (Option)

Tracks Up to 16 Satellites, 1575.42 MHz

Device GPS Accuracy < 15m, 95% Typical

Velocity Accuracy 0.05m/s

Heading Accuracy 0.3 Degrees

Horizontal Position Accuracy > 10m

NFC (Option)

Compliant with ISO/IEC 14443 A/B, 15693/18092, Distance 2.5mm

I/O INTERFACE

Sensors

Gyroscope

Light Sensor

Compass

Audio

1x Built-In Microphone

1x Internal 8ohm 1W speaker

Ports

1x USB 2.0

1x Micro USB @ 1A

1x Micro HDMI Output Type D

1x Audio Jack (3.5mm, 4 Pole, MIC input)

1x DC Jack 5.5mm OD Jack

Buttons

Power

Volume +, Volume –

2x Programmable

Barcode Reader (Option)

Newland NLS-EM2096, Built-In 1D/2D

Fingerprint Reader (Option)

Capacitive

MECHANICAL

Chassis

Front: Plastic + TPU Rubber, Back: Plastic

Dimensions

237 x 159 x 17mm

Weight

0.75kg

POWER

AC Adapter

12V DC 3A Output, 100-240V AC input, Standard US Plug

Options:

Medical AC Adapter

Multi-Nation Plugs

Battery

24WHh Battery, Li-on Polymer, 2S1P, 7.4V 3200mAh

ENVIRONMENTAL

Operating Temperature

0°C to 45°C

Storage Temperature

-20°C to 60°C

Humidity

10% to 90%

RoHS

Compliant

REGULATORY

Certification

FCC, IATA, IEC62133, IEC60601-1
