10.1″ Rugged Android Tablet PC | MS-100A

Certifications

ms_100a

Highlights

The 10.1” rugged tablet is designed for professionals across a wide range of demanding industries, including field services, logistics, construction, retail, and manufacturing. Featuring a vibrant IPS LCD display with 1920 x 1200 resolution, it ensures sharp, clear visuals even under direct sunlight. Powered by the Qualcomm SDM660 Octa-core processor, the tablet delivers robust performance, making multitasking and field applications seamless. Engineered for durability, it is equipped with IP67-rated water and dust protection and MIL-STD-810G certification for drop and shock resistance, ensuring reliable performance in harsh environments. With a long-lasting 12-hour battery, the tablet provides uninterrupted operation throughout the workday. The dock pogo connector allows for easy integration with optional peripherals, while the expansion bay supports modules like NFC, RFID, Smart Card Reader, Barcode Reader, and Rail Magnetic Stripe Reader, offering tailored solutions to meet the specific needs of industries such as warehousing, public safety, and transportation.

Features

10.1″ IPS LCD Display (1920 x 1200 Resolution)
Qualcomm SDM660, Octa-core Qualcomm® Kryo™ 260
Android 10
4ft Drop / Shock Protection (MIL-STD-810G)
IP67 Water & Dust Protection
Wi-Fi (2.4GHz & 5GHz), Bluetooth 5.0, GPS
Long Lasting Battery (12 Hours Standard Operation)
Dock Pogo Connector Supports Optional Peripherals
Expansion Modules: NFC Module, RFID Module, Smart Card Reader Module, Barcode Reader, Rail Magnetic Stripe Reader (can support up to 4 modules)

$799.00

in stock

DESCRIPTION

CONFIGURE & BUY

DESCRIPTION

Unmatched Performance with Qualcomm SDM660 Processor

The MS-100A Rugged Tablet PC is built to excel in any environment, offering a range of powerful processors to meet your specific needs. Choose between the Qualcomm SDM660 Octa-core processor for fast, efficient performance, the RockChip RK3588 with its Quad-core ARM Cortex-A76 and Quad-core ARM Cortex-A55 setup for enhanced power, or the Intel Elkhart Lake Pentium® N6415 processor for demanding industrial applications. Whether it’s for field data collection, logistics management, or real-time communication, the MS-100A delivers. Its 10.1″ high-resolution IPS touchscreen with 1920 x 1200 resolution provides crystal-clear visuals and a responsive interface, making it easy to access and analyze data. With 4GB LPDDR4 RAM and 64GB eMMC storage (upgradable to 6GB RAM and 128GB storage), this tablet is built to handle a wide range of tasks with ease.

Rugged Design for Extreme Conditions

Built to withstand the toughest environments, the MS-100A is designed with IP67-rated water and dust protection and is MIL-STD-810G compliant, ensuring drop and shock resistance from up to 4 feet. It can handle shocks, vibrations, and extreme temperatures, making it perfect for outdoor use in industries like construction, logistics, and field services. The 350-nit display, with an optional upgrade to 800 nits for sunlight readability, ensures that the screen remains clear even in bright outdoor conditions, making it ideal for professionals in unpredictable environments.

Versatile Connectivity and Expansion Modules

Stay connected with the latest wireless technology, including Wi-Fi 802.11 a/b/g/n/ac, Bluetooth 5.0, and optional 4G LTE, enabling seamless communication and real-time data transfer in industries like warehousing, logistics, and transportation. The tablet’s Pogo docking connector supports easy integration with optional peripherals such as keyboards and docking stations. Additionally, the MS-100A supports various expansion modules, including NFC, RFID, Barcode Reader, Smart Card Reader, and Rail Magnetic Stripe Reader, offering customizable solutions for industries ranging from retail to manufacturing.

Built for Long-Lasting Use

The MS-100A comes equipped with a powerful 3.85V, 7792mAh battery that provides up to 12 hours of operation, ensuring uninterrupted use throughout long work shifts. Support for Quick Charge 3.0 minimizes downtime, allowing for fast recharging and maximizing productivity across multiple applications, whether it’s for warehouse inventory audits, field inspections, or logistics tracking.

Engineered for Harsh Environments

Designed to thrive in extreme working conditions, the MS-100A can operate in temperatures ranging from -10°C to 50°C and be stored in temperatures between -20°C and 60°C, making it highly reliable in both cold and hot environments. This rugged tablet is the ideal solution for industries requiring durability and consistent performance, whether indoors or outdoors.

SPECIFICATIONS

RUGGEDNESS

Waterproof

IP65, IEC60529

Options:

IP 67

Drop Rating

MIL-STD-810G, 6 ft to plywood and 4ft to concrete

Shock Rating

MIL-STD-810G, Method 516.6, Procedure I, 40g 11ms

Vibration Rating

MIL-STD-810G, Method 514.6, Procedure I, Category 4

ESD Protection

6KV Touch, 8KV Air

EMC Test

MIL-STD-461F, CE101, CE102, CS101, CS114, CS115, CS116, RE101, RE102, RS101, RS103

SYSTEM

Processor

Qualcomm SDM660, 8 Core Cryo 200, 4x 2.2GHz and 4x 1.8GHz

Options：

RockChip RK3588, 4x Cortex – A76, 4 Cortex-A55, NPU 2.0, 8K VPU

Intel Elkhart Lake SKU4, Base 1.2GHz, Turbo 3.0 GHz

GPU

Qualcomm 512GPU

Memory

4GB DDR4

Options:

6GB DDR4

Android 10

Storage

4GB RAM with 64GB eMMC

Options:

6GB RAM with 128GB eMMC

DISPLAY

Screen Size

10.1″ IPS

Resolution

1920 x 1200 (16:10) WUXGA

Brightness

350 NIT

Options:

800 NIT, Sunlight Readable

View Angle

+/- 80°

Contrast Ratio

800:1

Touchscreen

Capacitive 10-Point Multi-Touch

High Strength Harden Glass

Ultra Optical Bonding

Auto-sensing, Configurable to Wet and Gloved Touch

Options:

User Replaceable Anti-Glare Film

COMMUNICATIONS

Wi-Fi

802.11 a/b/g/n/ac Dual-Band 2.4GHz & 5GHz

Bluetooth

Bluetooth v5.0

4G/5G/LTE

4G/LTE Cat 6

GPS

GPS, GLONASS, BeiDou

Cold Start No More than 60s

I/O INTERFACE

Sensors

Gyroscope

Ambient Light Sensor

G-Sensor

Compass

Audio

1x Built-In Microphone

1x Internal 8ohm 1W Speaker

Camera

Front Camera: 5MP

Rear Camera: 13MP with Auto Focus LED Flash

Ports

1x USB 3.0 @ 750mA Type C

1x USB 3.0 @ 750mA Type A

1x Audio Jack (3.5mm, 4 Pole, MIC input)

1x Docking Connector (10-pin, 12V DC Input, 1 USB 2.0)

1x Optional SIM/TF Card Slot

Buttons

Power Button on/off (Hold 10s will reset the system)

Volume +, Volume –

2x Programmable Buttons

EXPANSION I/O

Expansion Modules (Option)

Newland NLS-EM3296, Built-In 1D/2D Barcode Reader

Magnetic Stripe Reader

OMNIKEY® 3121 Smart Card Module

UHF RFID Module

NFC Module

MECHANICAL

Chassis

Double Injection Molding with Mg-AI chassis, Rubber Protection

Dimensions

270 x 180 x 16mm

Weight

0.98kg

POWER

AC Adapter

Standard US Plug QC3.018W Quick Charge

Options:

Multi-Nation Plugs

Battery

3.85V, 7792 mAh

Battery Charging Time 3.5 Hours

ENVIRONMENTAL

Operating Temperature

-10°C to 50°C

Storage Temperature

-40°C to 70°C

Humidity

1% to 95% Non-condensing, -30° To 60°C, 5 Cycles Of 48 Hours

Thermal Shock

-30° to 70°C Within 5 Minutes, No Operating

RoHS

Compliant

REGULATORY

Certification

FCC, CE, IC, RoHS

Tablet Regulatory

Upon Request

Battery

UL/UN38.3

CONFIGURATION

BASE CONFIGURATION:

$799.00

per unit

in stock

ADD TO CART

Quantity:

Get Personalized Offer

Open this products and find more reference

Touch Type

Multi-touch projected capacitive

0.00

Multi-touch projected capacitive

0.00

details

hide

Multi-touch projected capacitive

View details

Optional Components

Magnetic Stripe Reader

+ $150.00

details

hide

Magnetic Stripe Reader

View details

NFC Module, ISO/IEC 14443A/14443B/15693, MIFARE 1K/4K

+ $80.00

details

hide

NFC Module, ISO/IEC 14443A/14443B/15693, MIFARE 1K/4K

View details

Docking Station: 2 USB2.0, 1 DC in.c

+ $149.00

details

hide

Docking Station: 2 USB2.0, 1 DC in.c

View details

Hand Strap

+ $25.00

details

hide

Hand Strap

View details

1D/2D Barcode Reader

+ $100.00

details

hide

1D/2D Barcode Reader

View details
