10.1″ Rugged Tablet PC | MD-100K

arrow
MD-100 Rugged Tablet PC Front
MD-100 Rugged Tablet PC Front Side
Rugged Tablet PC MD-100
Rugged Tablet PC MD-100
arrow
MD-100 Rugged Tablet PC Front
Certifications
products
md_100k

Highlights

The MD-100K Rugged Tablet PC is purpose-built for demanding healthcare environments that require both performance and durability. Featuring a 10.1″ high-resolution IPS LCD screen and powered by the Intel® Kaby Lake Core™ i5-8200Y processor, this tablet ensures fast, efficient computing for medical applications. Its rugged construction, including IP65 water and dust protection and MIL-STD-810G shock resistance, provides reliable operation in even the toughest conditions. Certified for medical-grade safety and electromagnetic compatibility, the MD-100K is ideal for applications such as telehealth, patient monitoring, and medical response units. With OEM/ODM customization options, including NFC, RFID, smart card readers, and more, it offers adaptable solutions to meet the unique needs of healthcare professionals.

Features

  • 10.1″ IPS LCD Screen (1920 x 1200 Resolution)
  • Intel® Kaby Lake Core™ i5-8200Y Processor
  • Windows 10 Pro (Optional: Windows 10 Enterprise, Linux)
  • 4ft Drop / Shock Protection (MIL-STD-810G)
  • IP65 Water & Dust Protection
  • Sunlight Readable LCD Display (800nits)
  • Intel AX210 Wi-Fi 6E, Bluetooth 5.2, 4G LTE (Optional)
  • One Internal and One Hot Swappable Battery
  • Certified for medical-grade safety and electromagnetic compatibility
  • Optional Add-Ons: NFC Module, RFID Module, Smart Card Reader Module, Barcode Reader, Fingerprint Reader, Capacitive Stylus
$1,999.00
delivery
in stock
DESCRIPTION
CONFIGURE & BUY
DESCRIPTION
Rugged Tablet PC MD-100K

Unparalleled Power with Intel® Kaby Lake & Amber Lake Processors

The MD-100K Rugged Medical Grade Tablet PC delivers top-tier performance with options for the Intel® Kaby Lake Core™ i7-7Y75 or Intel® Amber Lake Y Core™ i5-8200Y processors. Designed for speed and efficiency, this rugged tablet is ideal for handling complex medical applications like patient data management, telemedicine, and electronic medical records. Its 10.1″ high-resolution IPS display (1920 x 1200) ensures crisp, clear visuals, and the device’s multitouch, water-splash-resistant screen provides a responsive interface even in challenging conditions. With up to 16GB LPDDR3 memory and M.2 SSD storage (up to 1TB), the MD-100K guarantees smooth performance for demanding healthcare and industrial tasks.

Rugged Design for Demanding Environments

Engineered to withstand harsh conditions, the MD-100K comes with IP65-rated water and dust protection, and MIL-STD-810G certification, providing 4ft drop and shock resistance. Whether in a hospital, an ambulance, or an outdoor medical response unit, this rugged tablet ensures durability and reliability in any environment. Its sunlight-readable 800-nit display guarantees excellent visibility in bright outdoor settings, making it ideal for medical teams on the move.

Rugged Tablet PC MD-100K
Rugged Tablet PC MD-100K

Flexible Operating Systems: Windows & Linux

The MD-100K supports Windows 10 Pro and Linux operating systems, giving healthcare and industrial professionals the flexibility to choose the platform that best suits their workflow. Whether you need the extensive features of Windows or the customizable open-source nature of Linux, the MD-100K offers seamless integration with your existing systems, making it an adaptable solution for a variety of applications.

Advanced Connectivity for Real-Time Communication

Stay connected and efficient with the MD-100K’s advanced connectivity features, including Intel® Wi-Fi 6E AX210, Bluetooth 5.2, and optional 4G LTE and GPS modules. These connectivity options ensure that medical teams can communicate and access critical data in real-time, whether they are in a hospital setting or responding to emergencies in the field.

Rugged Tablet PC MD-100K
Rugged Tablet PC MD-100K

Hot-Swappable Dual Battery System

The MD-100K is equipped with an internal battery and a hot-swappable dual battery system, ensuring continuous use throughout extended shifts. This system minimizes downtime by allowing healthcare professionals to quickly replace the battery without shutting down the tablet, ensuring uninterrupted performance in critical moments.

Customizable with Modular Add-Ons

Tailor the MD-100K to your specific needs with a range of optional add-ons. Available modules include a barcode reader, smart card reader, fingerprint scanner, NFC, and RFID. These add-ons enhance functionality, enabling secure patient data management, medication tracking, and efficient asset management.

Rugged Tablet PC MD-100K
Rugged Tablet PC MD-100K

Certified for Medical-Grade Safety

The MD-100K is certified to meet stringent medical-grade safety standards, including IEC 60601-1 and IEC 60601-1-2. These certifications ensure that the tablet can be used safely in sensitive medical environments, such as operating rooms, ICUs, and patient monitoring systems, while maintaining compliance with essential electromagnetic compatibility and safety standards.

SPECIFICATIONS

RUGGEDNESS

Waterproof
IP-65
Drop Rating
MIL-STD-810G, 4ft to Plywood on 26 Corners
Shock Rating
MIL-STD-810G, Method 516.6, Procedure I, 40g 11ms
Vibration Rating
MIL-STD-810G, Method 514.6, Procedure I Category 4, Category 20, Category 24
ESD Protection
8KV Touch, 15KV Air

SYSTEM

Processor
Kaby Lake Core i5-8200Y
GPU
Intel® HD Graphics 505, Base 200MHz, Burst 750MHz, Max Video Memory 8GB
Memory
8GB LPDDR3-1866
Options:
16GB LPDDR3-1866
OS
Window 11 LTSC
Window 11 Pro
Storage
256GB SSD M.2 Interface
Options:
512GB SSD M.2 Interface
Security
Intel AES New Instructions
Options:
TPM 2.0

DISPLAY

Screen Size
10.1″ IPS
Resolution
1920×1200
Brightness
800 NIT, Sunlight Readable
View Angle
+/- 85°
Contrast Ratio
800:1
Touchscreen
Capacitive 10-Point Multi-Touch
Auto-sensing, Configurable to Wet and Gloved Touch
Chemical Harden Cover Glass
Multi Touch Mode (Includes Water Splash)
Glass Coating Options:
Anti-Reflective
Anti-Glare
Anti-Fingerprint
Anti-Polarization

COMMUNICATIONS

Wi-Fi
802.11 a/b/g/n/ac Dual-Band 2.4G & 5G
Bluetooth
Bluetooth v4.2
4G LTE (Option)
4G LTE Sierra EM7455 (Verizon)
GPS (Option)
Ublox NEO-M10
NFC (Option)
SM-MSN13-C03
w/ote: NFC and RFID are mutually exclusive

I/O INTERFACE

Sensors
Gyroscope
Light Sensor
Compass
Audio
1x Built-In Microphone
1x Internal 8ohm 1W speaker
Camera
Front Camera: 2MP
Rear Camera: 5MP with Auto Focus
Ports
1x USB 3.0 @1.5A Type A
1x HDMI Output: Type A
1x Audio Jack (3.5mm, 4 Pole, MIC input)
1x DC Jack 5.5mm OD Jack
1x Docking Connector (12V DC Input, 2x USB)
1x RJ45 Port: 10/100/1000M
1x Micro SIM Slot
Buttons
Power Button
Windows Button
Volume +, Volume –
2x Programmable Buttons
Barcode Scan Button (with Barcode Option)
RFID (Option)
HID OMNIKEY® 5127
w/ote:NFC and RFID are mutually exclusive
Barcode Reader (Option)
Newland NLS-EM3596
Smart Card Reader (Option)
HID Omnikey 3121
w/ote: CAC and RFID are mutually exclusive
Stylus(Option)
Basic Stylus
Digitizer pen - eGalax

MECHANICAL

Chassis
Plastic + TPU
Options:
Anti-Microbial Medical Chassis
Dimensions
280 x 256 x 23mm
Weight
1.1kg

POWER

AC Adapter
19V DC 3A Output, 100-240V AC Input
Options:
Medical AC Adapter, 12V DC 3.3A Ouput, 100-240V AC Input
Battery
Hot Swappable Battery
Options:
Extra Hot Swappable Battery

ENVIRONMENTAL

Operating Temperature
0°C to 50°C
Storage Temperature
-20°C to 60°C
Humidity
10% to 90%
RoHS
Compliant

REGULATORY

Certification
FCC 47 CFR PART 15B & PART 15C, IEC60601-1, IEC 60601-1-2:2014, IEC62133, MSDS, UN38.3, EN 55032, EN 301489, EN 55035, EN 300328, EN 55032, EN 303413, EN 50663, EN61000, EN 62368-1
